USER GUIDE

Your OculosPro Camera has just arrived, but you are not sure what to do next. We are here to help you understand your camera.

Please follow the easy user guide to help you set up your new OculosPro Camera.

Charging the Battery.

1. Open the waterproof rubber covering the charging port.
2. Please use the provide micro-USB cable to fully charge your camera before use, this is important. When charging the button light will light up red. This will go off when the camera is 100% charged.

3. Please note that you can continue the battery life by using a portable power bank and the camera will continue to record.

How to insert the Micro SD Card

4. Open the waterproof rubber covering the Memory Card Slot.
5. Insert the FREE mini 64GB SD card and press it in gently. You can use up to 128GB.
6. To remove it, gently press the SD card and it will pop out. Do not remove the card if recording as it may damage the card.

7. Download the App ROADCAM, Switch the camera on with one press, then connect the WIFI to your phone via the app.
8.

You are all most finished.

8. A short press on the raised button, will switch on the camera and an orange light will appear, it will then vibrate, to let you know it is recording. The automatic recording blue light remains on for a long time.
9. Press the button once to START or STOP the recording. When stopped you will see a slow flashing blue light, to indicate it has stopped recording.

10. To switch off the camera press the button for 3 seconds and it will switch off completely.

Remote Control Function.

1. The recording button can start or pause recording.
2. Lock Key, press for 2 seconds, indicator light flashes blue and video is locked successfully.
3. WIFI Key, press once to turn ON or OFF. Green light stays on when WIFI is turned on.

Fixing it to your helmet.

We have a wide selection of mounts that can be used for a number of sports not depending on a helmet for us. If you are using a helmet, It can be placed on the top or side of cycling helmet and on the side for motorbike and horse riders helmets.

• When attaching the camera to the hat band, attach the quick release clip to the rotating bezel, which allows you to adjust the camera angle to your required view. Then push the camera through the circular mount up to the rubber no slip band and tighten with the easy grab

 Quick Tip – Check out the angle on the app in the live view section.

If there are still unanswered questions that you would like help with, please call 0151 678 7182 or email the office, info@equisafety.com
